Technical characteristic:

- rotor dimensions:    ~ Ø750 x 1300 mm
- inlet dimensions:     ~ 370 x 1310 mm
- outlet dimensions:   ~ 900 x 1360 mm
- capacity:                  ~ 40 t / h
- input graining:         - 20 ÷ 25 mm
- output graining:       - 0 ÷ 5 mm (80%)

The crusher's capacity and the obtained product granulation depend on the gap in the grate used.

- drive: electric motor:                 - 55 kW, 1500 rpm
- hydraulic device drive:              - 2.2 kW
- weight:                                      ~ 5.000 kg
- coal moisture:                           - max. up to 8%
- bearing temperature sensor:    - 2 pcs
- crusher motion sensor:             - pcs. 1
